Male ORB (#8) x Female NPT (1/2″)

$4.71

Male ORB x Female NPT Adapter.

  • Size: #8 (3/4-16) ORB x #8 (1/2-14) NPT
  • Pressure rating: 5000 PSI (345 bar)
  • 4:1 Safety Factor

All of the flow meters we sell come with ORB (SAE) ports. We offer a variety of adapters to assist you in adapting your flow meter or flow meter test kit to any connection.

Don’t see the adapter or size you need? GIVE US A CALL!

SKU: HC-MOFP-8-8 Categories: ,
Print Friendly, PDF & Email

Additional information

Weight .25 lbs
Dimensions 2.5 × 2.25 × 2.25 in
Type

Male O-ring x Female Pipe (SAE to Female NPT)

Working Pressure

Up to 5000 PSI
(Up to 345 Bar)

Thread Size (1)

#8 ORB (SAE)

Thread Size (2)

1/2" NPT
